USES锛
This equipment is widely used in environmental protection, epidemic prevention, workstock, chemical pharmaceutical, drug test, fishery and other areas of research experiment and production department. It is the specialized thermostatic equipment for water analysis, BOD test, and bacteria, moulds and microorganism cultivation and storage, as well as plant cultivation and seed-breeding test.
CHARACTERISTICS OF STANDARD FORMINCUBATOR锛
1.Stainless steel inner chamber; foursquare semicircle transition, convenient to clean; space between shelves is adjustable.
2.Micro-computer control system ensures precise and reliable temperature control; LCD enables multiple groups of data to be displayed at a time; ultraviolet germicidal lamp.
3.Independent humidification, sterilization and temperature limit system with function of over-temperature alarm and auto-power-cut-off.
4.Test hole of 锟52mm at left side of container.
5.Double airtight door structure.
6.Fluoride-free refrigeration.
7.Manual Temperatwre Control.
CHARACTERISTICS OF FUNCTIONAL FORM INCUBATOR锛
1. Intelligent programmed temperature and humidity control system with program of 30 to sections ensure timing, repeated or multistep running of temperature and humidity.
2. No freezing thanks to intelligent refrigeration and defrosting system.
3. Function of auto running, auto stopping and timing running, as well as parameter memorizing, power reset recovering and temperature display revising.
4. Watch timer and independent temperature safety device, which auto breaks off when over temperature limit.
5. Function of self-diagnosis,over temperature protection.
Optional accessories:
a. Printer: RMB1150 (desktop)
b. Supplementary oxygen, nitrogen interface: RMB200
c. RS485 interface and communication software interface: RMB800
MAIN TECHNICAL PARAMETERS锛
Model |
voltage
锛圴锛 |
Tem.
variation
锛堚剝锛 |
Tem.dis-
tinguish-
ability锛堚剝锛 |
Tem.
fluctua-tion
锛堚剝锛 |
Tem.
uniformity
锛堚剝锛 |
Hum-
idity
variation
锛堚剝锛 |
Hum-
idity
error |
Heat-
ing
power |
Refri-
gerant |
Standard
form
|
MJX-70B鈪 |
220V/
50HZ |
Humidifi
c-ation
锛10-65鈩
no humidi
-fication
锛0-65鈩
|
0.1鈩 |
High tem
锛0.5鈩
low tem
锛±1鈩
|
±1鈩 |
60-90%
RH |
5-8%
RH |
300W |
R134a |
MJX-150B鈪 |
500W |
MJX-250B鈪 |
800W |
Func-
tional
form
|
MJX-70BX |
300W |
MJX-150BX |
500W |
MJX-250BX |
800W |
Model |
Interior
dimensions
W×D×H(mm) |
Exterior
dimensions
W×D×H(mm) |
Packaging dimensions
W×D×H(mm) |
Gross/net
weight锛坘g锛 |
Timing range |
Ambient
tem.
锛堚剝锛 |
Standard
form
|
MJX-70B鈪 |
420×350×500 |
570×560×1020 |
730×720×1170 |
69/92 |
1-9999
min
|
5-30鈩 |
MJX-150B鈪 |
500×400×750 |
640×620×1270 |
820×760×1430 |
86/114 |
MJX-250B鈪 |
500×500×950 |
660×700×1470 |
880×825×1645 |
100/139 |
Func
tional
form
|
MJX-70BX |
420×350×500 |
570×560×1020 |
730×720×1170 |
69/92 |
MJX-150BX |
500×400×750 |
640×620×1270 |
820×760×1430 |
86/114 |
MJX-250BX |
500×500×950 |
660×700×1470 |
880×825×1645 |
100/139 |
