USES锛
Applications of this equipment in industrial and mining enterprises, labs and scientific research institutions include drying, melting, baking and sterilization etc.
CHARACTERISTICS锛
1. Cold rolling steel electrostatic spraying exterior; stainless steel or cold rolling steel corrosion-resistant inner chamber.
2. Optional pointer meter or intelligent temperature controller with PID program and digital display, with function of timing and over-temperature protection.
3. Door with double-layer tempered glass for clearly observation.
4. Door with silicon rubber seal ensures good sealability.
5. Low-noise fan unique design of air channel keep good uniformity of temperature studior.
MAIN TECHNICAL PARAMETERS锛
Model |
voltage锛圴锛 |
Tem.variation锛堚剝锛 |
Tem.fluctuation锛堚剝锛
|
Heating power(kw)
|
202-0AB |
220V/50HZ |
RT+10-250鈩 |
±1.0鈩 |
1.2 |
101-0AB |
1.2 |
202-1AB |
1.6 |
101-1AB |
1.6 |
202-2AB |
2 |
101-2AB |
2 |
202-3AB |
4 |
101-3AB |
4 |
Model |
Interior
dimensions
W×D×H(mm) |
Exterior
dimensions
W×D×H(mm) |
Packaging
dimensions
W×D×H(mm) |
Load per rack |
Net weight
锛坘g锛 |
Gross weight
锛坘g锛 |
202-0AB |
350×350×350 |
600×510×570 |
760×640×720 |
15/kg 2 for
standard
configuration
|
32 |
36 |
101-0AB |
350×350×350 |
650×510×525 |
800×640×670 |
33 |
37 |
202-1AB |
450×350×450 |
700×510×670 |
880×640×810 |
44 |
49 |
101-1AB |
450×350×450 |
750×510×625 |
910×640×760 |
45 |
50 |
202-2AB |
550×450×550 |
800×600×770 |
970×750×920 |
61 |
67 |
101-2AB |
550×450×550 |
850×600×725 |
1010×740×870 |
62 |
68 |
202-3AB |
600×500×750 |
965×706×1065 |
1160×840×1190 |
76 |
95 |
101-3AB |
600×500×750 |
965×706×1065 |
1160×840×1190 |
77 |
96 |
