USES锛
This equipment is widely used for drying, curing, melting and heating in experiments of industrial enterprises, scientific research institutions, and health and medicine units etc.
CHARACTERISTICS锛
1. COLD ROLLING STEEL ELECTROSTATIC SPRAYING EXTERIOR.
2. FAVIN STAINLESS STEEL OR COLD ROLLING STEEL INNER CHAMBER; FOURSQUARE SEMICIRCLE TRANSITION; FLEXIBLE POSITIONING AND REMOVABLE SHELF; AIRDUCT LATERAL PLATE AND BOTTOM HEATER COVERING ARE EASY ASSEMBLY AND DISASSEMBLY FOR CONVENIENT CLEANING.
3. PID MICRO-COMPUTER INTELLIGENT TEMPERATURE CONTROLLER WITH ACCURACY; FUNCTIONS OF TIMING, OVER-TEMPERATURE PROTECTION; DUAL DIGITAL TUBE DISPLAY OR LED, EASY TO READ.
4. DOOR WITH WIDE DOUBLE-GLASS OBSERVATION WINDOW, ADJUSTABLE AIR-TIGHT BUCKLE LOCK AND SILICON RUBBER SEAL, WHICH EFFICIENTLY PREVENTS HEAT LOSS.
5. HEATING POWER WITH HIGH AND LOW GEARS.
OPTIONAL ACCESSORIES:
A. MULTI-STAGED TEMPERATURE CONTROLLER: RMB1500 (DOMESTIC), RMB3000 (IMPORT);
B. LIQUID CRYSTAL SCREEN TEMPERATURE CONTROLLER: OPTIONAL LONG-DISTANCE CONTROL SYSTEM: RMB800.
FUNETIONSL TYPE:
1.LED
2.INDEPENDENT TEMPERATURE SAFETY DEVICE;CUTO BREAK OFF WHEN OVER TEMPERATURE LIMIT ,AND AUTO POWER SWITCH TO MAINTAIN SAFE EXEPERIMENT.
MAIN TECHNICAL PARAMETERS锛
Model |
standard |
WHL-30(B) |
WHL-45(B) |
WHL-65(B) |
WHL-125(B) |
functional |
WHLL-30BE |
WHLL-45BE |
WHLL-65BE |
WHLL-125BE |
Voltage(V) |
220V/50HZ |
Tem. variation(鈩) |
RT+10~300鈩 |
Tem. fluctuation(鈩) |
±1.0鈩 |
Tem. distinguishability(鈩) |
0.1鈩 |
Ambient tem(鈩) |
+5锝40鈩 |
Heating power(kw) |
0.8 |
1 |
1.5 |
2.5 |
Interior dimensions W×D×H(mm) |
310×310×310 |
350×350×350 |
400×360×450 |
500×450×550 |
Exterior dimensions W×D×H(mm) |
460×510×695 |
500×550×735 |
550×550×840 |
636×680×915 |
Packaging dimensions W×D×H(mm) |
550×570×765 |
620×585×800 |
640×640×905 |
730×720×1000 |
Load per rack(kg) |
15/kg 2 for standard configuration |
Gross/net weight(kg) |
33/37 |
37/43 |
44/49 |
60/66 |
Timing range |
1-9999min |
